Shiva Amvaj Super Volt Ammeter 96B

  • Ten in one
    • Three ammeters
    • Three current maximeters
    • A voltmeter (measures 6 voltage parameters ST,RT,TS,T,R,S)
    • A voltage maxi meter
    • A voltage mini meter
    • A frequency meter

  • Display:
    • Phase voltages (RST) relative to neutral and linear voltages (RS,RT,ST)
    • Display phase current simultaneously
    • CT over current warning
  • Display and record:
    • Max and min grid voltage
    • Max current
  • Options:
    • Voltage lock
    • Fixed and rotational voltage display
    • Displays grid frequency
    • Adjusts and displays CT
  • Displays each parameter with respective indicators
  • Data backup in case of power supply failure
  • Terminal wiring and installation manuals

  • Supply voltage: 180-250 VAC/R-N/50-60 Hz
  • Input voltage: 300-500 VAC/3PH/50-60 Hz
  • Measurement accuracy:
    • Voltage:±1V
    • Current: ±0.5%±1digit
    • Frequency: ±0.1 Hz
  • Operating conditions
    • Temperature: -20 to 65 o C
    • Humidity: 70%
  • Current transformer ratio selection according to the desired CT: 5/5-6000/5 A
  • CT adjustment time: five minute from connecting to electricity
